VTW400 Series Torch Rotation Welding Machinery

  Previous

 Catalogue              Instruction               Youtube

1.)Platform max load : 800Kgs.

2.)Torch rotation speed : 1.2 - 12.0RPM.

3.)Distance between rotate centre and platform : 0 - 400mm.

4.)Distance between rotate centre and vertical slide : 400mm.

5.)Torch rotation radius : 10 - 75mm.

6.)Clamp center strok : 120mm.

7.)Overlap timer adjusts : 0 - 99.9sec.

8.)Start / Crater arc timer : 0 - 99.9sec.

9.)Propose cooperating with welder 2 cycle / 4cycle start and welding manually.

10.)Control the function

11.)Use explain
