VOL-D25L30 Lifting Seamer

1.) Torch mobile is the use of a rack with a DC motor
2.) Platen using a pressure hose with a special aluminum seat, so that the workpiece can really pressing
3.) Rail is made of a copper alloy, and having a back blow hole and water circulation passage
4.) Each piece platen width is 100mm, and material is copper alloy
5.) Torch travel speed: 180 ~ 1,800 mm / min, and have digital display
6.) Beam axle locks device is locked to rotate pneumaticvoperation by a side, protecting operator's security
7.) Operating platform adopts twin screw and electric operation
8.) The Carrier Car is equipped with a set of rollers, which can electrically adjust the welding position of the workpiece
9.) The rollers on the Carrier Car can be adjusted height electrically
10.) Propose cooperating with welder 2 cycle / 4 cycle start and welding manually
11.) Can hold the MIG, MAG, TIG and Plasma welding torch
